Interchangeable Products
- Artech 30310
- Celtron SQB
- HBM A35
- Revere 5123
- Rice Lake RL30000, RL35023
- Sensortronics 65023
- Tedea 3411
- Totalcomp TSB
- Coti Global CG-23
Specifications:
Rated Output (mV/V): 3.00±0.015
Nonlinearity: ±0.02%FS
Hysteresis: ±0.02%FS
Repeatability: ±0.01%FS
Creep (30 minutes): ±0.02%FS
Zero Balance: ±1.00%FS
Temperature Effect on Zero: ±0.02%FS/10°C
Temperature Effect on Output: ±0.02%FS/10°C
Input Resistance: 385±5Ω
Output Resistance: 350±3Ω
Insulation Resistance: ≥5000MΩ
Excitation Voltage: 10V(DC/AC)
Compensated Temperature Range: -10°C ~ 50°C
Operating Temperature Range: -20°C ~ 60°C
Safe Overload: 120%FS
Cable: 5.4x6 m
Cable Color Code: Input: Red (+) Black (-) Output: Green (+) White (-)
